Medical Device Emergency Supplier Room Beds for Patient Transfer

Product Description

Product Name: Electric Displacement Machine

Model: SD-SX-S01

This product is suitable for the transportation of patients who cannot move independently, such as severe spinal trauma patients, postpartum women, surgical patients, and patients with severe cardiovascular and cerebrovascular diseases, especially for the care, examination, treatment, surgery, etc. of patients who are tall and overweight.

1, Function configuration:

This product features a unique quick action design that allows the moving bed board to move outward while the bed surface automatically rotates, ensuring that patients can move smoothly and comfortably between the bed and the transfer cart without the need for any lifting when lying, sitting, or lying on their side. It is more flexible for transporting patients to and from various testing rooms, operating tables, CT, CR, and for disabled elderly people to change beds, bed sheets, and bedding. only one person is needed to complete the entire process, which requires four or more people to carry and lift. Effectively avoiding further injuries caused by improper handling and greatly reducing the labor intensity of medical staff. Truly solved the transportation difficulties for patients with fractures, cerebral hemorrhage, postoperative conditions, overweight patients, and critically ill patients. The bed body can be electrically raised and lowered to meet the height requirements of different departments' beds, operating tables, etc. It has functions such as automatic and semi-automatic pick-up and drop off, manual pick-up and drop off, emergency stop, etc.

2, Technical parameters:

1. Specification: Total length 2020mm, total width 850mm, adjustable height 600-870mm. Surface length 180mm, width 650mm, board width 480mm (allowable deviation ± 20mm).

The net weight of the bed is 165KG, and the gross weight is 235KG (allowable deviation ± 2KG).

2. The bed frame is welded with high-quality steel pipes, which are firm and not deformed. It is treated with spray coating, which has antibacterial effect, durability, and chemical corrosion resistance. The bed frame adopts 40 × 60 square tubes and 30 × 60 square tubes with a thickness of 1.2mm, and the main connecting parts of the bed body are formed by 3mm cold plate stamping. The bed surface is made of thickened high-quality stainless steel plate, which can bear a weight of ≥ 200kg.

3. Guardrail: ABS hydraulic folding guardrail, hydraulic support, and drop buffering.

4. The bed frame is made of high-density polyethylene (HDPE) resin material and blow molded in one piece.

5. There are 2 transmission shafts on the bed surface, and a solid and wear-resistant conveyor belt is laid around it, which can rotate forward and backward. Install stainless steel handrails at both ends for easy implementation.

6. Equipped with a high energy storage lithium battery, it can transport patients about 150 times within 6 hours of charging.

7. The motor adopts a silent high-power motor with high performance, low noise, stable output, and durability.

8. Casters: Equipped with 8-inch medical silent universal wheels, acid and alkali resistant, corrosion-resistant, anti winding, not easy to rust, central control of brake pedal, stable and reliable braking, smooth rolling without noise, flexible and lightweight, anti bumping, and firm braking.

9. Comes with 1 detachable infusion stand as standard

(1) The infusion rack comes with four hooks as standard, which can be retracted and lowered

(2) Material: Stainless steel pipe frame with resin upper and lower locking components

(3) Equipped with damping device: It can slow down the infusion rod and adjust the height and fix it by rotating the upper and lower locking parts

3, Product configuration:

Silent wheel, guardrail, infusion rack, controller, battery, motor, complete machine frame, manual, warranty card

4, Product packaging:

The packaging of the transfer bed is made of wooden boxes.


Product Parameters

Detailed Photos
