- Pixel Pitch：
- P1.25
- Refresh Rate：
- 3840hz
- Module size：
- 320*160mm
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
| Parameter Name | Product Parameters | |
| Unit Parameters | Pixel pitch (mm) | 2.5mm |
| Pixel configuration | 1R1G1B | |
| LED type | SMD | |
| Unit resolution | 256*192Dots | |
| Pixel density | 160000pixels/M2 | |
| Module size | 320mm(W)x160mm(H) | |
| Unit size (WxHxD) | 640mm×480mm | |
| Scan and drive mode | 32-sweep constant current driver | |
| IP Rating | IP20 | |
| Maintenance type | Front maintenance | |
| Optical and Electrical Parameters | Brightness | ≤600cd/M2 |
| Unit power (maximum)) | 680W/M2 | |
| Unit power (typical) | 270W/M2 | |
| Color temperature (adjustable) | 3200K-9300K | |
| Viewing angle | H:≥140° ;V:≥120 | |
| Max contrast ratio | ≥3000:1 | |
| Brightness control | Manual | |
| Input Voltage | AC 90~264V | |
| Input power frequency | 50/60Hz | |
| Gray scale (bits) | 16bit | |
| frame Rate | 50/60Hz | |
| Refresh frequency (Hz) | 3840Hz | |
| Usage Parameters | Lifespan | ≥50000Hours |
| Recommended viewing distance | 4M | |
| Operating temperature | -10ºC~+40ºC | |
| Storage temperature | -20ºC~+60ºC | |
| Communication connection | CAT5 cable transmission( L≤100m );Single-mode fiber( L≤15km ) | |
| Statement: Power is for reference only, the specific to the actual prevail, specifications are subject to change without notice. | ||
FAQ:
Q: How about your delivery time?
A:Generally. it will take 15 to 25 days after receiving your advance payment.The spe-cific delivery time depends on the items and the quantity of your order.
Q: What kind of LED display do you offer?
A: Our products cover LED full color display for indoor and outdoor, rental LED display, LED advertisement display, LED stage display, LED sports display, LED irregular-shape display, customized LED display etc.
