- Mesh width：
- 1200/1600mm
- Welding electrode No.：
- 16/32
- Wire diameter：
- 2mm-3.5mm
Chicken cage mesh welding machine, mesh width 1200mm/1600mm, wire diameter: 2mm-3.5mm. welding speed: 60-80 strokes/min. , cross wire feeding in pre-cut wire, line wire feeding from coil wire
Standard configuration: wire payoff stand, main welding machine, cross wire hopper, mesh pulling device, mesh cutting machine, mesh dropping cart.
This machine adopts synchronous control technique, both the welding time and cent-control welding is controlled by PLC program system.
The input front-panel is in touch screen, it makes the machine more intelligent and reasonable.
The line wire feeding form is from coil wires directly or in pre-cut wire (you can choose it based on your requirements).
The cross wire feeding form is in pre-cut wires.
Both the line wire space and cross wire space can be adjusted freely within the required range.
The greatest advantage is that it can be adjusted the cross wire space at random on the same one piece of mesh panel or sheet.
Model | 1200/1600 |
Mesh width | ≤1200mm/≤1600mm |
Wire diameter | 2mm-3.5mm |
Cross wire space | ≥25mm |
Line wire space | 50mm-200mm |
Welding electrode No. | 16/32 |
Cross wire type | ≥400mm Pre-cut wire |
Line wire type | Coil wire |
Welding transformer | 125KVA*3 or 4 |
Welding speed | 60-96 strokes/min. |
Diagonal error | ±2mm(mesh sheet of 2 meter length) |
Mesh output form | Mesh sheet /panel |
Wire material | Cold drawn wire or galvanized wire |
