SCM2 Series Electric Centrifugal Water Pump
Applications and installation
Suitable for pumping clean water and chemically non-aggressive liquid.
Used for pressure boosting washing systems, cooling and fire-fighting units, Industrial water supplying.
Horticultural and agricultural irrigation applications, civil and domestic water transfer schemes, boiler, chiller and refrigeration systems.
Pumps should be installed in a covered area, protected against the weather.
Characteristic
The SCM series pumps are with two back-to-back impellers centrifugal pumps, higher head valve than
single impeller pumps
Extremely high outputs
Reliable, economical and simple to use
Construction features
Pump Body: cast iron
Motor Housing: aluminum/cast iron
Shaft: 45# steel/stainless steel
Impeller: brass
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44/IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ metalized carbon
Operating limitations
Max ambient temperature up to 40 ℃
Max fluid temperature up to 80 ℃
Max pressure up to 10 bars
The Graph
