- Model NO.：
- WJPS-350
- Certification：
A) Electric Control System: The main control unit adopts imported electric components, together with CPU via DOS system to control the servo motors
B) Shaftless Driving: The machine uses servo motor to drive the rollers directly, providing a guarantee for precise high-speed running.
C) Overprinting System: once printing length is input at the main control unit, every unit will move automatically to the preset position.
D) Printing Unit: Each unit can work independently, which enhance the production efficiency greatly. There is a touch screen on each unit, you can work easily.
E) Water And Ink Control: The machine adopts advanced American water and ink supplying system which ensures the water and ink balance, stability at low and high speed and bright print result.
F) Lubricating System: The machine uses automatically cycling oil-supply system to ensure the accuracy and service life of the machine.
G)The computer controlled automatic and manual plate mounting and dismounting system shortened the plate changing time and increases the safety level of the machine. ( Plate changing for 6 color only needs 6 minutes)
H) The Japanese origin SMC Pneumatic clutch pressure control system ensures smooth and accurate running of the machine; Twice clutching done by Japanese Fujikoshi three point suspension bearing, makes the PS plate and the water blanket fully pre-inked and then be pressed which greatly reduces the pre-print paper wastage.
I) 7 o'clock arrangement of the rollers, high precision servo drive, twice clutching control and color lose prevention system make high quality prints and competitiveness of the machine.
J) Heidelberg ink fountain partition structure, easier to adjust the ink, reducing printing time and paper waste.
Options:
--Automatic Registration system
---Automatic ink control system
---Flexo press unit
---Die cutting unit
---Embossing unit
---Cold foil unit
---Hot foil unit
Technical Parameter
| Items | Specifications | Unit |
| MaxWebWidth | 370 | mm |
| Max.PrintingArea(W*L) | 350*345 | mm |
| DiameterOfUnwindingWeb | 600 | mm |
| DiameterOfRewindingWeb | 600 | mm |
| ThicknessOfPrintingMaterial | 60-350 | g/m2 |
| PrintingLength | 130-345 | mm |
| PrintingSpeed | 30-200(Subjecttothelengthandqualityoftheprintingmaterial,Max70m/min) | times/min |
| Power | 29.8for6color(4.7/color) | KW(threephase380V)50/60HZ |
| UV | 4.8/color | KW(threephase380V) |
| OverallDimensions | 8500*2000*1600(L*W*H)for6color | mm |
about US
Hebei Wanjie Machinery Technology Co.,Ltd founded in 1999, is lodacted in northern China printing machinery production base-Yutian City. We have more than 100 employees and 4000 square meters building.
We are one of the leader manufacture for label machinery, our CE standard products have offset ,letterpress, flexo label printing machine, label die cutting , slitting , inspection, rewinding machines.
CNC Workshop
We have own CNC workshop to make machine body structure and parts accessories which ensure the quality and accuracy
