- Model NO.：
- MR-TF
- Certification：
Product Application
At present, with development of such industries as pharmacy and food, more and users need rotary sterilizers. This kind of sterilization is still based on general sterilization principle (sterilization with saturated steam). But sterilization vehicle continues backward and forward rotation at an adjustable speed via magnetic drive unit inside of equipment. The power of rotation is unique driving device invented by our company.
Steam Pressure: 0.4-0.6Mpa
Designed Pressure: 0.17-0.30Mpa
Water pressure: 0.2-0.3Mpa
Working Pressure: 0.15-0.27Mpa
Compressed Air Pressure: 0.5-0.7Mpa
Working Temperature: 134ºC
Main Features
1.The box is designed, produced and tested strictly according to <Steel Pressure Vessel>
2. Electrically balance door, flexible and easy to operate.
3. The unique design of embedded dove-computer PLC and touch screen and DCS long distance tiring-room monitoring system.
4. Stainless steel wiring-drawing plate for decoration case.
5. Standard GMP certification port.
6. Stepless variable-frequency speed control.
7. Design and work pressure is selected according to characters of sterilized articles.
Technical parameter
| Model | Inner Chamber size(L x W x H) | Overall Size(L x W x H) single/double Door | Net Weight kg | Steam consumption kg/cycle | Control Power AC220/50Hz/kw | Power supply 3-AC380/50Hz/kw | Water consumption kg/cycle | Cooling water consumption kg/cycle | Compressed air consumption m³/cycle |
| MR-MD-0.5 | ∅1100x580 | 1825x1905x1850 | 2200 | 90 | 0.5 | 4.5 | 300 | 800 | 5 |
| MR-MD-1.2 | ∅1250x2300 | 3460x1980x2000 | 3500 | 170 | 0.5 | 5.5 | 600 | 1800 | 8 |
| MR-MD-2.5 | ∅1400x3080 | 3200x2130x2120 | 5800 | 300 | 0.5 | 7.5 | 1000 | 3500 | 12 |
| MR-MD-5.0 | ∅2000x3100 | 3500x2800x2800 | 7500 | 580 | 0.5 | 12.5 | 1600 | 7000 | 15 |
| MR-MD-8.0 | ∅2000x4850 | 5250x2800x2800 | 9700 | 700 | 0.5 | 16.0 | 2000 | 11000 | 20 |
| MR-MD-10 | ∅2500x4100 | 4600x3200x3300 | 12000 | 850 | 0.5 | 20 | 2300 | 14000 | 25 |
| MR-MD-12 | ∅2500x4800 | 5300x3200x3300 | 13500 | 1000 | 0.5 | 22 | 2500 | 19000 | 31 |
