Description:
Our factory adopts advanced stainless steel welding technology abroad, selecting the fine polished stainless steel tube, which has improved greatly comparing with the former products we manufactured. Manual control, it is suitable for the liquid material, such as fresh milk, fruit milk, wine, juice, soybean milk and Chinese medicine, as well as the sticky material (for example, sweat condensed milk) upon completing with high-pressure homogenizer.
Equipment list:
| Items | Name of machine | Model | Size | Qty. |
1 | Main machine | RP6L10 | 1000*700*1250 | 1set |
2 | Reverse tank | / | 280*280*305 | 1set |
3 | Centrifugal pump | / | / | 1set |
4 | Connection pipes | / | / | 1suit |
| 5 | Spare parts | / | / | 1suit |
Characteristics:
It is continuous production, and the sterilization time is very short.
Due to the shorter time heating, it can obtain high quality products.
With ultra high temperature sterilization, the sterilization efficiency is very high.
Using centrifugal pump and high pressure homogenizer, the application range is very wide, and it is suitable for sterilizing high viscosity material.
Small steam consumption.
Technical parameter:
| Project Model | UHT-1 | UHT-2 | UHT-3 |
| Processing Capacity (L/h) | 700-1000 | 1500-2000 | 3500-4000 |
| Sterilizing temperature(centigrade) | 115-135 | 115-135 | 115-135 |
| Sterilizing time(s) | 4-6 | 4-6 | 4-6 |
| Material outlet temperature(centigrade) | Less than 65 | Less than 65 | Less than 65 |
| Motor power (kw) | 2.2 | 3 | 4(6) |
| Steam pressure (Mpa) | 0.78 | 0.78 | 0.78 |
| Steam consume(Kg per liter material) | 0.15 | 0.15 | 0.15 |
| Size(mm) | 1314*925*1650 | 1500*1050*1800 | 1750*1350*2000 |
