The1year
- Model NO.：
- 14L, 17L, 23L
- Certification：
- CE, ISO13485
1. LCD display, 8 programs Automaticly feeding water and draining water system easy to operate.
2. Full-Automatical operation, check and monitor by computer
3. Printer inside, note the sterilization process in details
4. Automatic and safety door lock system
5. Have an enaluation system of sterilization process
6. According to Europer B standard, with 3 times pre-vacuum
7. The water setting is full-automatic
8. Can show the reason of failure on LCD, do not need to check recording to code menu
9. Seprate steam generator
10. Multi-language convient for different customers, now we have Language of Germany, Italy, Polish, Turkey, Spanish, Hungary, Lithuania, French, English, Russia, etc.
11. New type of separate steam generator
12. The temperature accurate to the first decimal place, the pressure accurate to the second decimal place.
13. Have very detail print. Can make the record of monitoring temperature and pressure per 6 seconds.
Safety Devices:
A. Over heat control: When inner temperature is overheated, power will be shut down Automaticlly and alarm system
B. Over pressure control: It has alarm system when over pressure.
C. Automatic, multi-protections and Safety door lock system
D. Low water level indictor: It has alarm system when low water
Warranty: 2 years warranty time,during this period, we will support you free parts for maintenance if necessary, out of date, you should bear the spare parts cost and the shipping cost, of course we will support you free technical service for lifetime !
After service:
Please contact with the telephone and emails at any time.
Because of the time difference, therefore, sending Email is the best and convient way to contact us. Upon receipt of your e-mail, we give u reply immediately, offering solutions to equipment failures. Tonsor will extend the greatest effort to help your getting spare parts, speeding up your feed-back to customer demand.
QC:
100% inspection and random check on the parts and machine, ensure 100% products with high quality.
Package: 1PCS/CTN
Transportation: By air, by sea, by express
| Model | T& S 14B+ | T& S 17B+ | T& S 23B+ |
| ChamberDimensions(mm)(Φ × D) | 250× 270 | 250× 380 | 250× 500 |
| Chamber Capacity(liter) | 14L | 17L | 23L |
| Overall Size(cm)(L× W× H) | 48× 48× 52 | 48× 56× 42 | 48× 67× 42 |
| Heater | 1600W | 1800W | 2000W |
| Net Weight(KGS) | 37 | 46.5 | 56 |
| Gross Weight(KGS) | 45 | 55 | 65 |
| Packing Size(cm) | 68× 60× 50 | 73× 60× 50 | 87× 60× 50 |
| Minimum Desk Size(cm) | 48× 35 | 48× 40 | 48× 50 |
| Power Supply | 220± 10%, 50/60HZ, 10A | ||
| Sterilize Temperature | 121/134 | ||
| Sterilize Time | Please refer to different programs. | ||
| Dry Procedure | Vacuum drying | ||
| Sterilizer Construction | Stainless steel SUS#304 | ||
| Water tank | Internal | ||
| Stainless steel instrument container | 5 trays | ||
