- Model NO.：
- YX-WY-80DM
- Certification：
- CE
Overall Dimensions(LXWXH)mm:990x640x1680
Chamber Size(∅XL)mm: ∅420x580
Steam Consumption(KG):≤10
Water Consumption(KG):≤30
System Power(Kw):≤2kw
Built-in Steam Generator Power(Kw):≤12kw(optional)
N.W Single Door(KG):250
Main Technical Parameter
Design pressure:-0.1~0.3Mpa
Working pressure:0.245Mpa
Vacuum:-0.086Mpa
Water Pressure:0.1~0.2Mpa
Steam Pressure:0.3~0.7Mpa
Design temperature:144ºC
Working Temperature:105~138ºC
Temperature Equilibrium:<+2.0ºC
Compressed air pressure:0.4~0.7Mpa
Power voltage:Three-phase five-wire AC 380V 50Hz
Features
Horizontal circular inner chamber + jacket structure, safety, heat preservation, and drying function ;
Disc type embedded gear + Electric lock door structure,safety and reliable;
Door seals are pneumatic or self-expanding
Equipped with standard equipment verification interface
Pipeline system for the optimal design. SUS304 pipeline, clamp structure, quick assembly
Control system: HMI man-machine interface, touch screen + microcomputer;
F0 value and temperature time double guarantee sterilization effect, with perfect sterilization records;
With program selection, parameter setting, equipment operation, report processing and
traceability Functions;
Multiple safety protection(over-temperature, over-pressure protect)
Sterilization process: fabric, equipment, liquid, BD, pressure testing, custom defined multiple procedures
