The1year
- Model NO.：
- LDZH
- Certification：
- CE, ISO13485
Product Features1.Intelligent microcomputer control system:Using LED digital control system, After sterilization finished sterilizer will automatic alarm and shut down.
2.Electric Interlock device:The control system can real time supervision the sterilizer chamber's temperature and pressure. only under the safety temperature and pressure can open the sterilizer's cover, Make sure the operator's safety.
3.The structure of cover's opening:Using 8 rotary extendable stick to improve sealing and safety performances.
4.Preset program:Can preset fixed program that sterilize solid body.
5.Memory storage system:Store the last operation program so convenient next operation.
6.Interface check:Provide temperature and pressure check interface; convenient to check multiple position temperature measurement.
7.Digital display screen:Digital display screen and working indicator light display running state.
8.Safety devices:Electric Interlock device, overtemperature and over pressure protecting system, burned protection, safety relief valve, current leakage protector and automatic fault detection.
Technical Parameter
| Parameter/Model | LDZH-100KBS | LDZH-150KBS | LDZH-200KBS |
| Configuration | Semi-automatic control | Semi-automatic control | Semi-automatic control |
| Main body material | Stainless steel | ||
| Volume/GW | 100L / 187kg | 150L / 200kg | 200L / 217kg |
| Voltage/Power | 380V/6kW | ||
| Packing size (LxWxH) | 760x800x1340mm | 760x800x1530mm | 760x800x1720mm |
| UseVolume (DxH) | 650x650x1200mm | 650x650x1400mm | 650x650x1700mm |
| Sterilization chamber volume (DxH) | 500x550mm | 500x760mm | 500x1000mm |
| Basket size (DxH) | 465x230mmx2 | 465x230mmx3 | 465x230mmx4 |
| Time setting range | 0-99 h | ||
| Rated working pressure | 0.217Mpa | ||
| Sterilization Temp setting range | 50-134 C | ||
12 months for the whole machine. Within 12 months under normal use and maintenance, if something is wrong with the machine, you will get spare part for free. Out of 12 months, you will get spare parts at cost price. You will also get technical support and service all the lifetime. Technical Support
1. Technical support by phone, email or WhatsApp or Wechat or Skype around the clock.
2. Friendly English version manual and operation video.
After sales services
Normal machine is properly adjusted before dispatch. You will be able to use the machines immediately. You will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by email/fax/tel and lifetime technical support.
