Ming Pfizer series medical plasma air disinfectant products are mainly composed of fans, junior high-efficiency filters, plasma modules and activated carbon molecular filters.
Indoor polluted air is circulated through various disinfection and purification modules under the action of fans. The primary filter mainly filters large particles such as hair and dust; the plasma module can effectively kill various bacteria, viruses, fungi and other pathogenic microorganisms in the air; the activated carbon molecular filter can effectively remove organic gases and various odors in the air ; This series of products can effectively achieve the disinfection effect of the hospital-type disinfection environment.
Widely used in: all kinds of hospital operating room, ICU, supply room, delivery room, checkout room, pathological room, laboratory, office, baby room, access to international, sterile, therapeutic room, general wards, treatment room,transfusion room, blood dialysis room, oral planting room, and personnel to dense, prone to cross infection in public places, etc.
Product Parameters
| Specification model | HR-XDY-100 |
| Dimensions(mm) | 325×420×825 |
| Weight(kg) | 25 |
| Rated air volume(m³/h) | 1000 |
| Noise(dB(A)) | ≤55 |
| Plasma intensity(KV) | 8 |
| Applicable volume(m³) | ≤100 |
| Operating hours(min) | ≥60 |
| Power(W) | 110 |
| Life(year) | 5 |
Product features
Working principle
The main bactericidal factor: plasma.
Sterilization principle: Kill bacteria in the air through plasma.
Microbicidal category: it can kill common bacteria in the air.
Suitable for air disinfection in medical and health institutions and public places
In a confined space of no more than 100m3, at room temperature and relative humidity no more than 80%, the machine can be turned on continuously for more than 60 minutes to meet the air disinfection requirements.
Equipment installation
This machine is a mobile model, which can be used in multiple rooms. It should be placed in a place that is sturdy, not susceptible to vibration, and enough to bear the weight of the unit; choose not to be close to the heat source and steam source, which will not cause obstacles to the air inlet and outlet of the unit Place; choose a place where the wind can be sent to every corner as much as possible; choose a place close to the power socket, and leave enough space near the machine.
Product Pictures
The following are our company's best-selling products,can be viewed on the company website
After-sales service
Maintenance
1. Unplug the power plug before cleaning and maintenance.
2. Do not make the electrical system damp when cleaning, so as to avoid accidents and malfunctions.
3. Maintenance period
| Parts | Cycle | Method | |
| General occasion | Specially polluted occasions | ||
| Primary filter | 12 months | 6 months | Open the back cover and take it out to clean and replace |
| High efficiency filter | 2 years | 1 year | Please inform the company to arrange for professionals to guide the replacement |
| Plasma generator | 2 years | 1 year | Please inform the company to arrange professional staff to guide maintenance |
The primary filter is a consumable material, which is not covered by the warranty, and the material cost is borne by the user
After-sales service
1. This product is guaranteed for one year from the date of sale (the warranty period is subject to the sales contract). If a malfunction occurs during the warranty period, it is indeed a quality problem identified by the company, and the company is responsible for free repairs. If the damage is serious and cannot be repaired, it shall be replaced.
2. The initial effect and high efficiency filter are consumable materials, which are not covered by the warranty, and the material cost is borne by the user.
3. After the warranty is exceeded, the company will provide lifetime maintenance services for the products, and customers need to pay maintenance fees and material costs.
4. Those who fall into one of the following situations are not included in the scope of free service, but can be repaired for a fee.
A. Consumers are damaged due to improper use, maintenance and storage;
B. The whole machine and parts have exceeded the free warranty period;
C. Damage caused by dismantling by the maintenance department of our company or not;
D. The model of the Three Guarantees certificate is inconsistent with the model of the repaired product or is altered;
E. Damage caused by force majeure such as natural disasters;
F. The product fails or is damaged due to accidental factors or man-made reasons.
Shandong Huirui Medical Technology Co., Ltd. is the wholly owned subsidiary of Huirui (Shandong) Environmental Technology Co., Ltd., which is one of the member units of laboratory construction and design in Shandong Province, a high-tech enterprise specializing in the design, construction, operation and maintenance of the related products to laboratory and purification. The company was established in 2012 and has been dedicated to laboratory and purification field for 9 years. Our company always adheres to the concept of "quality first and continuous innovation" to provide customers with safer, more healthy, energy-saving and humanized solutions as well as timely and thoughtful operation and maintenance service.
Logistics and freight forwarding
FAQ
1.Why choose Huirui?
We are the leading manufacturer in medical shelters like the interfrated mobile container PCR laboratory, nucleic acid testing shelter, etc, and other lab equipments, OEM & ODM service are offered.
2. What payment terms do you accept?
T/T, L/C ,D/A, D/P.
3.How about your delivery time?
Within 15-30 workdays after receiving deposit.
4.What is the shipping port?
FOB to Qingdao Port, China(also can ship according to customers' request).
5.How to inspect the goods?
Products will be checked by our QC staff first, then our project manager.Client can come and check by themselves or third party check is available.
6.What's your warranty?
One-year warranty period is provided.
7. What should I do if I don't know how to use?
Please do not worry, manual user will be sent together. We provide online training after-sale service, to make sure our customers can operate our instruments skillfully.
