Submersible muddy water pump
The volute casing of pump is equipped with the impeller of Single channel or double channel. The pump is suitable to handle the wastewater or dirty water with solid grain or fiber etc. impurity. The sealing oil chamber is equipped with a high-precision anti-interference leakage detection sensor, and the stator windings are embedded with thermal elements to automatically protect the pump motor. Mechanical seal adopts new hard corrosion resistant titanium tungsten material. WQ sewage submersible pump can be equipped with double guide rail automatic coupling installation system according to the requirements of users. The pump can be also equipped with float ball switch for automatic control pump start and stop according to the change of liquid level.
High efficiency, energy-saving, Anti-winding, no clogging, automatic installation and automatic control.
This submersible pump has corrosion resistant type, high temperature resistant type, explosion proof type and so on.
| pump | caliber | capacity | head | power | speed | efficiency |
| model | mm | m3/h | m | KW | r/min | % |
| 25 WQ 8-22-1.1 | 25 | 8 | 22 | 1.1 | 2900 | 38.5 |
| 32 WQ 12-15-1.1 | 32 | 12 | 15 | 1.1 | 2900 | 40 |
| 40 WQ 15-15-1.5 | 40 | 15 | 15 | 1.5 | 2900 | 45.1 |
| 40 WQ 15-30-2.2 | 40 | 15 | 30 | 2.2 | 2900 | 48 |
| 50 WQ 20-7-0.75 | 50 | 20 | 7 | 0.75 | 2900 | 54 |
| 50 WQ 10-10-0.75 | 50 | 10 | 10 | 0.75 | 2900 | 56 |
| 50 WQ 20-15-1.5 | 50 | 20 | 15 | 1.5 | 2900 | 55 |
| 50 WQ 15-25-2.2 | 50 | 15 | 25 | 2.2 | 2900 | 56 |
| 50 WQ 25-20-2.2 | 50 | 25 | 20 | 2.2 | 2900 | 56 |
| 50 WQ 18-30-3 | 50 | 18 | 30 | 3 | 2900 | 58 |
| 50 WQ 25-32-5.5 | 50 | 25 | 32 | 5.5 | 2900 | 53 |
| 50 WQ 20-40-7.5 | 50 | 20 | 40 | 7.5 | 2900 | 55 |
| 65 WQ 25-15-2.2 | 65 | 25 | 15 | 2.2 | 2900 | 52 |
| 65 WQ 37-13-3 | 65 | 37 | 13 | 3 | 2900 | 55 |
| 65 WQ 25-30-4 | 65 | 25 | 30 | 4 | 2900 | 58 |
| 65 WQ 30-40-7.5 | 65 | 30 | 40 | 7.5 | 2900 | 56 |
| 65 WQ 35-50-11 | 65 | 35 | 50 | 11 | 2900 | 60 |
| 65 WQ 35-60-15 | 65 | 35 | 60 | 15 | 2900 | 63 |
| 80 WQ 40-7-2.2 | 80 | 40 | 7 | 2.2 | 1450 | 52 |
| 80 WQ 43-13-3 | 80 | 43 | 13 | 3 | 2900 | 50 |
| 80 WQ 40-15-4 | 80 | 40 | 15 | 4 | 2900 | 57 |
| 80 WQ 65-25-7.5 | 80 | 65 | 25 | 7.5 | 2900 | 56 |
| 100 WQ 80-10-4 | 100 | 80 | 10 | 4 | 1450 | 62 |
| 100 WQ 110-10-5.5 | 100 | 110 | 10 | 5.5 | 1450 | 66 |
| 100 WQ 100-15-7.5 | 100 | 100 | 15 | 7.5 | 1450 | 67 |
| 100 WQ 80-20-7.5 | 100 | 80 | 20 | 7.5 | 1450 | 68 |
| 100 WQ 100-25-11 | 100 | 100 | 25 | 11 | 1450 | 65 |
| 100 WQ 100-30-15 | 100 | 100 | 30 | 15 | 1450 | 66 |
| 100 WQ100-35-18.5 | 100 | 100 | 35 | 18.5 | 1450 | 65 |
| 125 WQ 100-15-11 | 125 | 100 | 15 | 11 | 1450 | 62 |
| 125 WQ 130-20-15 | 125 | 130 | 20 | 15 | 1450 | 63 |
| 150 WQ 145-9-7.5 | 150 | 145 | 9 | 7.5 | 1450 | 63 |
| 150 WQ 180-15-15 | 150 | 180 | 15 | 15 | 1450 | 65 |
| 150 WQ 180-20-18.5 | 150 | 180 | 20 | 18.5 | 1450 | 75 |
| 150 WQ 180-25-22 | 150 | 180 | 25 | 22 | 1450 | 76 |
| 150 WQ 130-30-22 | 150 | 130 | 30 | 22 | 1450 | 75 |
| 150 WQ 180-30-30 | 150 | 180 | 30 | 30 | 1450 | 73 |
| 150 WQ 200-30-37 | 150 | 200 | 30 | 37 | 1450 | 70 |
| 150 WQ 160-45-37 | 150 | 160 | 37 | 37 | 1450 | 70 |
| 200 WQ 300-7-11 | 200 | 300 | 7 | 11 | 980 | 73 |
| 200 WQ 250-11-15 | 200 | 250 | 11 | 15 | 980 | 74 |
| 200 WQ 250-15-18.5 | 200 | 250 | 15 | 18.5 | 1450 | 72 |
| 200 WQ 400-10-22 | 200 | 400 | 10 | 22 | 1450 | 76 |
| 200 WQ 400-13-30 | 200 | 400 | 13 | 30 | 1450 | 73 |
| 200 WQ 300-15-22 | 200 | 300 | 15 | 22 | 1450 | 73 |
| 200 WQ 250-22-30 | 200 | 250 | 22 | 30 | 1450 | 71 |
| 200 WQ 350-25-37 | 200 | 350 | 25 | 37 | 1450 | 75 |
| 200 WQ 400-30-55 | 200 | 400 | 30 | 55 | 1450 | 70 |
| 250 WQ 600-9-30 | 250 | 600 | 9 | 30 | 980 | 74 |
| 250 WQ 600-12-37 | 250 | 600 | 12 | 37 | 1450 | 78 |
| 250 WQ 600-15-55 | 250 | 600 | 15 | 55 | 1450 | 75 |
| 250 WQ 600-20-55 | 250 | 600 | 20 | 55 | 1450 | 73 |
| 300 WQ 500-15-45 | 300 | 500 | 15 | 45 | 980 | 70 |
| 300 WQ 800-15-55 | 300 | 800 | 15 | 55 | 980 | 73 |
| 300 WQ 600-20-55 | 300 | 600 | 20 | 55 | 980 | 75 |
| 300 WQ 800-20-75 | 300 | 800 | 20 | 75 | 980 | 78 |
| 300 WQ 950-20-90 | 300 | 950 | 20 | 90 | 980 | 80 |
| 300 WQ 1000-25-110 | 300 | 1000 | 25 | 110 | 980 | 82 |
| 350 WQ 1100-10-55 | 350 | 1100 | 10 | 55 | 980 | 84.5 |
| 350 WQ 1500-15-90 | 350 | 1500 | 15 | 90 | 980 | 82.5 |
| 350 WQ 1200-18-90 | 350 | 1200 | 18 | 90 | 980 | 83.1 |
| 350 WQ 1100-28-132 | 350 | 1100 | 28 | 132 | 740 | 83.2 |
| 350 WQ 1000-36-160 | 350 | 1000 | 36 | 160 | 740 | 78.5 |
| 400 WQ 2000-15-132 | 400 | 2000 | 15 | 132 | 740 | 85.5 |
| 400 WQ 1700-22-160 | 400 | 1700 | 22 | 160 | 740 | 82.1 |
| 400 WQ 1500-26-160 | 400 | 1500 | 26 | 160 | 740 | 83.5 |
| 400 WQ 1700-30-200 | 400 | 1700 | 30 | 200 | 740 | 83.5 |
| 400 WQ 1800-32-250 | 400 | 1800 | 32 | 250 | 740 | 82.1 |
| 500 WQ 2500-10-110 | 500 | 2500 | 10 | 110 | 740 | 82 |
| 500 WQ 2600-15-160 | 500 | 2600 | 15 | 160 | 740 | 83 |
| 500 WQ 2400-22-220 | 500 | 2400 | 22 | 220 | 740 | 84 |
| 500 WQ 2600-24-250 | 500 | 2600 | 24 | 250 | 740 | 82 |
