- Model NO.：
- BKQ-B50L
- Certification：
Features:
* Standard built-in printer.
* Deionized water interface for supplying steam generator.
* F0 value display and printed.
* Rapid water cooling system for efficient and safe sterilization of liquids.
* With a quick maintenance window, the electrical parts can be repaired without removing the cover.
* Microcomputer control. Fully automatic control water injection, temperature rise, sterilization, exhaust and dry.
* LCD screen display shows pressure, temperature, time and error codesand operation curve etc.
* Mobile probe detects to ensure the internal temperature of liquid directly, to ensure the sterilization effect of liquid program.
Product Parameters
Model | BKQ-B50L | BKQ-B75L | |
Capacity | 50L | 75L | |
Chamber Size(mm) | φ386*490 | φ386*670 | |
Chamber Material | SUS304 | ||
Designed Pressure | 0.28MPa | ||
Designed Temp | 150ºC | ||
Working Pressure | 0.22MPa | ||
Working temp. | 80ºC-136ºC | ||
Temp. Display Accuracy | 0.1ºC | ||
| Noise | ≤65dB | ||
Power Consumption | 5.5KW | ||
| Power Supply | AC110/220V±10%, 50/60Hz | ||
External Size(W*D*H)mm | 700*610*1100 | ||
Package Size(W*D*H)mm | 800*715*1270 | ||
Gross Weight(kg) | 140 | 147 | |
