Description
The machine is newly designed based on advanced technologies from Germany, Italy and Taiwan. Its optional working process can be divided into3 stages, circulating hot heater spraying, warm water pre-cooling, cold water cooling.Temperature and time of cooling can be regulatedaccording to the requirements of user. It is suitable forcooling /heatingall kinds of bottles or canned hot beverage and aerated beverage. It equips with "Rexnord" (American famous brand) chain plate, which is made of high temperature resistance polypropylene (CPP). The main body is made of excellent stainless steel. Thus the machine is more reliable in running, also it has abeautiful appearance.
Features
1) The chain plate is abrand product
2) The conveyor is frequency controlled
3) All nozzle and spray tubes are made of stainless steel and spray evenly
4) The catchments flume is made of stainless steel and equipped with alevel alarm device
5) The spray-cooling tunnel has aspray cooling recycling water pump and steam adjustment valve
6) Steam consumption is adjusted according to the temperature
7) 304Stainless Steel machine frame and machine body...
Parameters
Production capacity (b/h) | 6000-9000 |
Temperature (ºC) | 37-45 |
Cooling time (min) | 12-15 |
Conveying speed | 100-550 |
Width of chain (m) | 1.22 |
Steam pressure (MPa) | <4 |
Water consumption (m3/h) | 9 |
Steam consumption (kg/h) | 120 |
Motor power (kw) | 7.55 |
Dimension (mm) | 15800*1500*1700 |
| Pasteurizing time( min) | 10--30 | Pasteurizing temperature | 65-98ºC,adjustable |
| Width of conveyor (mm) | 1000/1200/1500 | Running speed | frequency control |
| Voltage | 380v/50HZ (or customized) | Power | Conveyor motor: 3kw |
| Circulating water pump: 4kw | |||
| Steam pressure | 2kg, 0.3MPa | Capacity(bottles/h) | 1500-2500 |
| Dimension(mm) | 10000*1500*1750 or 12000*2200*1750 (according to your capacity and pasteurizing time) | ||
Production line in client's factory
Machine setup and commissioning
After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.
Contact information
Please write to us with below information for getting detailed quotation sheet quickly:
- What is the filling material;
- What is your bottle type and cap type;
- How many bottle types that you have;
- How many bottles per hour you will produce;
