The1year
- Model NO.：
- THR-ZW003
- Certification：
- CE
Product DescriptionTHR-ZW003 Hospital ultraviolet sterilization lamp Air Sanitization
254nm Ultraviolet Lamps UV Lamp
High Intensity UVC Lamp THR-ZW003,has two pcs of 30 watts or 55 watts UV lamps that emit a high intensity ultraviolet light that hits every surface in the room and kills any micro organisms or pathogen including MRSA,hand foot mouth disease,colds and flu,pneumonia,molds,e.coli,salmonella and similar type bacteria.The light penetrates and destroys the actual DNA of micro organisms. There is no known micro organism that is immune to UV-C energy.
Application:
The High Intensity UVC Lamp trolley is mainly applied in sterilization and disinfection of the air in operating room,ICU,treatment room and ward, it could be also be applied in sterilization and disinfection of other rooms of which the air is required being sterilized.
Hospital: operating room, manufacturing laboratory, ward, treatment room, toilet
Blood station: blood sampling room, bioclean room, blood bank
Food and beverage: manufacturing shop, changing room, laboratory
Features:1.High Intensity UVC Lamp disinfects approximately up to 30 square meters room area.
2.There are numerous safety features bulit with a 0-120mins timer.
3.High Intensity UVC Lamp has numerous applications not just for hospitals but can be used in schools,play areas,hotels,clinics,homes,cinemas, buildings,food manufacturing companies and offices.
4.It quickly and effectively provide disinfection of all surfaces and air within minutes.
5.High Intensity UVC Lamp is laboratory tested ,used by hospitals and recommended by doctors.
Caution
- Don't look directly at the ultraviolet light source,should be used in unmanned circumstances.
- Ensure the surface clean of UV lamp,or will affect the performance.
-Keep in the dry and clean room.Should Extend the exposure time if the room temperature is below 20 degrees Celsius or above 40 degrees Celsius.
-When sterilizing the surface of object,should illuminate directly within 1m between the ultraviolet light and surface.
-When sterilizing pet or animal room,please make sure pets don't touch the ultraviolet sterilizer.Please protect the eyes and skins of pets with shading cloth.
-Open the window and ventilation for 10 minutes after sterilization.
Method of Usage
1.Install the base with body.
2.Open the protection door.
3.Lift the lamp arm and adjust to 90,135,180 degrees. 4.Insert the plug and press 'ON' button ,adjust 0-120mins timer.
5.Leave the room right now.
6.After finishing sterilization,press 'OFF' button.
7.Adjust timer to 'stop'.
8.Hold down the 'adjustable button' to adjust lamp arm to the box .
9.Close the protection door.
10.Pull out the plug.
Product Parameters
| item | value |
| Type | ultraviolet sterilization Equipments |
| Brand Name | THR |
| Model Number | THR-ZW003 |
| Voltage | 110V, 220V,50Hz or 110V,60Hz |
| Working Time (hours) | 8000 |
| uv lamp tube | 30W*2 |
| Color Rendering Index(Ra) | 90 |
| Rated Power | 60W |
| Wavelength | 253.7nm |
| adjusting angle of the lamp arm | 0°-180° |
| UV Optiical Power(μW/cm2) | 214 |
| Application | Hospital/Blood station/Food and beverage |
| Tube Power | ≥30W×2 |
| Number of tubes | 2 |
| Applicable static area | ≥30m2 |
| Irradiance | ≥214uw/cm2 |
| Movable and foldable, the tube could be Concealed inside, can be adjusted to various angles | 30°, 60°, 90°, 135°, 180° |
| A timer equipment with the time limitation | 0-120 mins |
