Brand:SUZHOU PHARMA
Product name:Self Adhesive Labeling Machine
Max label size:360mm*60mm
Conveying direction:left-right; right-left
Min quantity:1件
Quantity:500件
Deliver:In 60 days
Characteristics
◆Using a new type of elastic pressure topping mechanism to ensure stable product delivery and
effectively eliminate the inherent error of bottle height;
◆The labeling is accurate and stable. It adopts PLC+subdivision stepping motor to drive the label delivery,
and the label delivery is accurate; the cam brake mechanism is adopted to ensure uniform tension to ensure
the tension of the label, reduce label breakage, and ensure accurate label detection; With detour correction
mechanism, it can prevent the label from shifting left and right, and ensure the accuracy of the label;
◆Powerful functions, color touch screen control, Chinese and English optional operation interface,
convenient and intuitive, powerful data memory function, can store 50 sets of labeling parameters, production
counting function, power saving function, production number setting prompt function, parameter setting
protection Function, convenient for production management, one-click switching of labeling for different
products, no need to repeatedly debug, simple and fast; and has a complete fault prompt and help function.
Applicable product range | Diameter: 20-150mm Height: 10-350mm |
Applicable label range | Height: 15-180 mm Length: 10-250mm |
Operating power（kw） | 0.18 |
Machine Model | SH-300 |
Drum Diameter | 300mm |
Max material load capacity | 20-30 lbs |
Max Rotating Speed | 1400r/min |
Motor Power | 1kw |
Machine weight | 300kg |
Machine Dimension | 580*550*600mm |
