Brand:SUZHOU PHARMA
Product name:Differential pressure sensor
Measuring range:(0-100) hPa, (0~40.15) in H₂O
Protection level:IP40
Min quantity:1件
Quantity:500件
Deliver:In 30 days
Buy
Absolute pressure accuracy ±3hPa;
Enter the altitude to calculate the atmospheric pressure;
Differential pressure measurement range 0~100 hPa;
Optional Picot tube can measure wind speed;
Temperature and air density compensation for more accurate measurement;
Built-in ten different measurement units (psi, fpm, hPa, m/s, etc.) to choose from.
Parameters | Pa, hPa, mbar |
Resolution | 0.01hPa, 0.01inH2o |
Measurement rate | 0.5 seconds |
Ambient temperature | (0~±50)℃ |
Power supply | 2 1.5VAAA batteries |
Overall Size (mm) | 119x46x25 |
Net Weight (g) | 90 |
