WORKING PRINCIPLE
Adding electrolyte in raw water,the water will be electrolysis in through the diaphragm cell,then at the side of anode will generate acidic aqueous solution which main content is hypochlorite (HCIO) and last we will get EOW(Full name:Electrolyzed oxidizing water/Acidic oxidized electrolyzed water/Acid oxidiation-potential water).Sodium hydroxide (NaOH) is formed from the cathode in strongly alkaline water.Acid water has function of strong oxidation so the water can kill microorganisms and sterilization.Alkaline water has function of anti - oil and protein and stripping emulsification so that it can remove organic matters.
STERILIZATION MECHANISM
The main component of acid oxidizing potential water is hypochlorous acid.Hypochlorous acid produces active hydroxyl (-OH) in the reaction process.Active oxygen (O2) can also generate H2O2 under the condition of high redox potential, and then generate hydroxyl (-OH).Active hydroxyl (-OH) is a strong oxidant, which can decompose and inactivate bacterial nucleic acid, protein and metabolic enzymes, leading to microbial death.
Characteristic:
1.Real-time online display parameters of ph, orp.And effective chlorine content, electrolytic current.
2.Automatic prompts of replacement supplies to ensure the Equipment work in the best state.
3.Automatic positive and negative pole washing, to ensure theService life of the electrolytic cell.
Main performance:
1.Touch screen display accompanied by sound alarm of large current,raw water shortage in order to ensure the normal Operation.
2.Display all the running status with color show, make more Clearly.
3.The ratio of salt concentration adjust as required, without Stirring, add oowder or globular electrolyte without stop running the equipment.
4.Electrolytic cell equipped with 12 pieces of electrode plates,Large electrolytic area make more stable with longer service life.
Firstly,wehave2kindsofEOWgenerator,namedHHEOWandHHSAEW.
Theintroductionandfunctionissame,thegeneratorcanproducedisinfectanttokillvirusindailylife.HHEOWmodelproducePH2-3solution,HHSAEWmodelproducePH5-6solution.Ithas60120180240300500L/H.TheCapacityiscustomized.WhenyougetthisEOWwatermachineinlocalplace,thecostofperliterdisinfectantsolutionproducedbymachineis aroundUSD0.015/L.Youcansellitafterpackedinto1L2L5L500mlbottles.
Secondly,thepreparedwaterisneededbeforeEOWgenerator:
Therequirementofinputwater:itshouldbepurifiedwater,wewillsuggest2advices:1.UsingROwaterpurifierandthenfeedingthepurifiedwaterdirectlyintoEOWwatermachine.2.Ifyourwater'sTDSlessthan200ppm,youcanusesoftwatermachineandthenfeedingsoftwaterintoEOWmachine.
Thirdly,abouttheConsumables:
1.Dailyconsumables:electrolyte,1kg/bag,whenneedtobeaddedaccordingtothedevicescreenprompts.
2.Largeconsumables:replacetheelectrolyticcell,normally1-1.5years.
| HHEOW Product Parameter | ||
| Item | Specs | Specs |
| Model | HHEOW-1000 | HHEOW-2000 |
| PH | 2-3 | 2-3 |
| Oxidation reduction potential (ORP) (MV) | 1100 min | 1100 min |
| Effective chlorine content (mg/L) | 50-70 | 50-70 |
| Residual chloride ion (mg/L) | 1000 max | 1000 max |
| Electrolyzed oxidizing water output (L/min) | 1 | 2 |
| Weight (KG) | 45 | 50 |
| Size (mm) | 550x550x1550 | 550x550x1550 |
| Application | Sterilization of environmental surfaces,food tableware and hand antisepsis.for life and for hospital,to wash hands, floors, and also can wash wound. | |
| Power | Ac220v 50hz | |
| Rated power:750va | ||
| Standby power≤10w | ||
| HHSAEW Product Parameter | ||
| Electrolyzed oxidizing water output (L/min) | 2 | |
| PH | 5-6 | |
| Oxidation reduction potential (ORP) (MV) | 600min | |
| Effective chlorine content (mg/L) | 40-80 | |
| Included | Control system (PLC + touching screen), electrolytic cell, monitor. | |
| Warranty and after-sales | Included 2 years free warranty. | |
We can also do the following products, if you have the need, please contact us:
1.HHOSWS HHECPW Sterility Water Treatment Machine For Stomato logy And Endoscopy Department
2..HHEOW HHSAEW Electrolyzed Oxidizing Water Generator Machine
3.HHHD Hematodialysis Water Treatment Machine For Related Department
4.HH Full-Automatic Water Softener For Sterilizing Room
5.HHRO-C Series Water Purifier For Sterilizing Room
6.HHRO-S Series Water Purifier For Sterilizing Room
7.HHUP UItra Pure Water Purifier For Laboratory Department
8.Pharmaceutical purified water system
9.Animal drinking water system
10.Medical Heat Sealing Machine
FAQ:
1.What s the payment term?
50% TT in advance(based on your qty maybe 30%), 50% balance against copy B/L in 7 workdays.
2.When will you arrange production?
In 7 workdays when we receive your advanced payment.
3. When will you send BL copy?
In 5-7 workdays after shipment date.
4. When will you send original documents?
In 3-5 workdays when we get the balance.
5. From we pay the advance to we get the goods what other service you can provide?
A Send photos from raw material to shipment.
B Notice and remind you when will you get the goods.
C Advise or Solve when you meet the problem during your production.
ZIBOJOYREACH NEW MATERIALS CO.,LTDis a leading ProjectInvestmentManagemententerprise of construction products in China.We mainly specializein materials'R&D,invest production cost,domestic saleand international exporting sale.
2010,establishes factory to produce hospital water treatment machines.It is a high-tech environmental protection enterprise which is integrating R& D, design, production, sales and service.Our advantage,equipped with automatic polishing and cutting equipment, modern production and processing, welding workshop, product experimental research and development center, electrical test room, water quality testing and analysis room, etc.
We focus on the research and development and manufacture of hospital water treatment machines, including hemodialysis water treatment machine, EOW water generator, purified water machine, softened water machine, laboratory ultra pure water machine, endoscope sterile water treatment machine, animal experimental water treatment machine, GMP pharmaceutical water system and other products, leading the development of the industry.It is deeply trusted by every worker in the medical field.
Withinnovation and developmentof economic and society,in 2009,we started to invest other instruction projects which named concrete water reducing admixture,named Polycarboxylate superplasticizer and Naphthalene superplasticizer.Concrete admixtures are widely used in concrete constructionprojects,national defense,power plant,water conservancy,railway,road,bridge,oil field etc.
Nowwehavebecomeaninternationalenterprisewithproduction,salesandtechnology.ZIBOJOYREACHiswillingtoworkwithfriendsfromallwalksoflife,andtryourbesttobecomenationalmajorprojectssupplier.Withadvancedtechnology,sophisticatedequipment,high-qualityproducts,excellentserviceandthemostcompetitiveprice,wemakeallbusinessbest,wholeheartedly,forcustomer.
