THREE SERVO INTELLIGENT PACKAGING MACHINE 450X
PRODUCT DETAILS
APPLCAITION
Suitable for food industry, pharmaceutical industry, toys and stationery, plastic products , industrial supplies , daily necessities , disposable products , hardware products , industrial parts , auto parts.
TECHNICAL PARAMETERS
Type ：450XN
Film width：Max：450mm
Bag length：130 -6000mm
Bag with：60 -200mm
Product height：Max：120mm
Film roll diameter：Max：320mm
Packaging rate：25- 120bag/min
Packaging materials：OPP,OPP/CPP, KOP/CPP,ALU - FILM
Power：220V，50/60Hz，5KW
Machine size：( L)3844×(W) 1050×( H) 1111
Machine weight：400Kg
Packing Size：Host1760*1270*1360 Tail frame2600*700*440
PERFORMANCE CHARACTERISTICS
-The bag length does not need to be set manually. It is automatically detected and set during the operation of the equipment .
-Three servo control , mechanical structure , easy maintenance , less wear and tear, long service life .
-Touch screen display, good man-machine interface , centralized and intuitive operation .
-The packaging speed and bag length are servo controlled , with stepless speed change , wide adjustment range , and can match the previous process of the production line .
-High sensitivity electric eye can automatically and accurately track .
-Each sealing temperature is independently controlled , suitable for packaging of various materials , and the sealing is beautiful and firm .
