Such textile reinforced hydraulic hose SAE 100 R3 is suitable for petroleum or water based hydraulic fluids deliver. It is mainly used in low pressure conditions and it is also used in pneumatic apps. It is composed of three parts: tube, reinforce and cover. The tube absorbs high quality oil resistant synthetic rubber. Because it doesn’t react with petroleum or water based hydraulic fluids. The reinforce absorbs two layers of braided textile, making the hose light in weight and flexible. Thus the hose is easy to operate. The cover absorbs high quality abrasion, corrosion, weather and oil resistant synthetic rubber. Therefore, the hose has a longer service life.
Recommended For:
Low-pressure hydraulic lines. Exceeds SAE100 R3 AT.
INNER TUBE: oil resistant NBR
REINFORCEMENT: two layers of high strength fiber braided
COVER: oil and weather resistant synthetic rubber
APPLICATION: petroleum and water based hydraulic fluids
SURFACE: wrapped and smooth surface are available
Temperature Range: -40℃ (-104℉ ) to +100℃(+212℉)
Standard: SAE 100 R3
