Festures
1. Temperature and pressure
Sterilization temperature: 105 to 135°C,designed pressure:..3Mpa
2. Big LCD Screen can clearly show all sterilization data and process.
3. Over temperature protection system
The system can monitor the temperature changes in the sterilization chamber on a real-time basis and disconnect power supply immediately upon detection of over temperature or abnormal temperature variation.
4. Automatic troubleshooting system
Troubleshooting is conducted automatically upon startup. Acoustic alarms will be given and Error Number will be displayed on the screen if any trouble occurs during equipment operation.
5. Safety and Function
Self-induction pressure interlocking device, lid closing checking, over temperature protection, temperature monitor, dry scorch protection system, over pressure pro tection, safety valve, over current and short circuit protection, leakage protection device, anti-scald safety protection, automatic troubleshooting system.
| Model | GI36TW | GI54TW | GI80TW | GI100TW |
| GI36TR | GI54TR | GI80TR | GI100TR | |
| Model difference | TW: Standard + cooling fan, TR:TW+drying | |||
| Capacity(L) | 36 | 54 | 80 | 100 |
| Dimension(L* W*Hmm) | 460x542x1070 | 460x542x1070 | 620x680x1100 | 620x680x1200 |
| Chamber dimension(Dia*H,mm) | ф325x460 | ф325x670 | ф400x709 | ф400x809 |
| Chamber material | SUS 304 | |||
| Rate power supply(w) | 2300 | 2600 | 4600 | 4600 |
| Power requirement | 22OV,16A.50/60HZ 220V,32A.50/60 HZ | |||
| Working environment | 5 45"C . relatively humidity 10%-85% | |||
| Stainless steel basket (Dia*H/mm) | (ф300x200)x2 | (ф300x200)x3 | (ф360x280)x2 | (ф360x220)x3 |
| Temperature accuracy | O.l°C | |||
| Working environment | 5 45"C, relatively humidity 10% 85% | |||
| Display system | LCD displayer | |||
| Sterilization temperature | 105-135°C | |||
| Sterilization time range | 1-6000 minutes | |||
| Melting temperature | 60-100 | |||
| Melting time | 1-6000 minutes | |||
| Warming temperature | 45-60 °C | |||
| Warming time range | 1 9999 minutes | |||
| Drying temperature(TR) | Drying time range 1-300 minutes, drying temperature:80-140°C | |||
| Sterilization cycle | Liquid .Liquid with warming Solid Instruments packed with doth Fabric RubberFast WasteAgar meltingSelfdefined Drying (onlyfordrying models) | |||
| Sterilization cycle number | Can save up to 60 cycles, record 1000 process, and USB port | |||
| Exhaust | Automatic internal discharging , with a steam collectingbottle inside. Exhaust speed can be selected by 6 levels. bottle inside. Exhaust | |||
| Preset range of timer | Can be preset and auto start up to 6 days in advance | |||
| Display range of pressure gauge | -0.l-0.5Mpa | |||
| Pressure | Max working pressure:0.25Mpa; Design pressure:0.3Mpa | |||
| Controller | "Smart IIII" fast speed microcomputer controller | |||
| Safety device | Self-induction pressure interlocking device, lid closing checking, over temperature protection, temperature monitor; dry scorch protection system, over pressure protection,safety valve,over current and short circu it protection, leakage protection device,anti-scald safety protection, automatic troubleshooting system | |||
