Table Top Autoclave Class B Series
BKM-ZB series sterilizer is an automatic high temperature and pressure rapid sterilizer which works with steam as medium. It can be widely used in department of stomatology and ophthalmology, operating room, supply room, dialysis room and other medical institutions. It is unpacked items, solid instruments, dental hand pieces, endoscopes, implantable instruments, dressing fabric and rubber tubes, etc.ntent="" style="background-color:#b4c6e7;padding:0 10px;margin:0;line-height:36px;text-align:left;">Detailed Photos
ntent="" style="background-color:#b4c6e7;padding:0 10px;margin:0;line-height:36px;text-align:left;">Product Parameters
Features:
1.Build-inopentypewatertank
Thesterilizeradoptseasy-cleanopentypewatertankwhichcansupportrepeatedprogramrunningiffullyinjectedwithwater.
2.High-efficiencyultimatevacuum
Thesterilizeradoptshigh-efficiencylownoisevacuumsystemwhichhasexcellenteffects.
3.LargeLCDdisplayforBKMZA/BKMZB
TheLCDscreencandisplaytemperature,pressure,time,operatingstatus,failurewarningandotherinformation.
Itisconvenientforcustomerstoobservethesterilizerrunningstatus.
4.Multipleprogramtypes
Thesystemhasvariousprogramsthatincludepackeditems,unpackeditems,BDtestingprogram,vacuumtestingprogramanddryingfunction.
Customprogram,rapidprogramandpreheatfunction(forBKM-Z16B).
5.StandardUSBportforBKMZA/BKMZB
UserscanstorethesterilizationdatawithUSBdisk.
6.Optionalminiprintercanbeattachedtorecordtheprocessofsterilization.
Models:
Model | BKM-Z16B | BKMZA (Perious name:BKM-Z18B) | BKMZB (Perious name:BKM-Z24B) |
Capacity | 16L | 18L | 23L |
Chamber Size(mm) | φ230*360 | φ247*360 | φ247*470 |
Sterilization Class | Class B (according toGB0646) | ||
Sterilization Temp. | 121ºC,134ºC | ||
Special Program | HIV, HBV long-sterilization program | / | |
Drying System | Vacuum drying system | ||
Display | LED display | LCD display | |
Testing System | B&D Test Vacuum Test Helix Test | ||
Control Precision | Temperature: 1ºC Pressure: 0.1bar | ||
Sterilization Data | BKM-Z16B:Printer(optional) BKMZA/BKMZB:USB(standard) and printer(optional) | ||
Safety System | Hand lock door Pressure lock system Relief valve in case of over pressure Pressure or temperature over load protection Alarm for system failure, finish reminding, water level warning | ||
Water Supply System | Build-in water tankeasy to clean | ||
WaterTankCapacity | 2L | 4L | |
Water Consumption | 0.4L in one cycle | 0.16L~0.18L in one cycle | |
Tray Holder | 3 pcs SS trays on SS shelf | ||
Chamber | SUS304 Max working pressure:2.3bar Min working pressure: -0.9bar Designtemperature: 140ºC | ||
Ambient Temp. | 5~40ºC | ||
Noise | <50dB | ||
Consumption | 1800W | 1950W | 1950W |
Power Supply | AC110/220V±10%,50/60Hz | ||
External Size(W*D*H)mm | 445*550*395 | 495*600*410 | 495*700*410 |
Packing Size(W*D*H)mm | 550*670*500 | 610*810*590 | 610*810*590 |
Gross Weight(kg) | 47 | 63 | 65 |
