Product Description
Features
1) Double unwinding and rewinding system;
2) Hydraulic meter displays pressure;
3) Auto web-guide works together with magnetic tension controlling system;
4) Photocell tracks print marks.
5) Servo motor/stepping motors are applied for controlling bag making length and speed;
6) Invertor is employed for better bag making;
7) Auto hole puncher;
8) Bags can be sealed one or two times according to different production requirement;
9) Bag forming results good precision and high speed;
10) It adopts heavy pressing bag forming method, the pressure is pressed equally on four points.
11) It is ideal equipment for making paper/paper, paper/plastic film medical bags;
Main Technical Parameters
| Model | BHLD-600 |
| Max. Dia. of unwinder | ф600mm |
| Max sealing width | 600mm |
| Max cutting length | 600mm |
| Production raw | 1~3raws |
| Suitable Material | Medical grade paper/CPP+PET compound film |
| Speed of reel making | 10-30metes/min |
| Speed of pouch making | 30~100cuts/min |
| Total power | 20KW |
| Weight | 3100KG |
| Overall dimension(L*W*H) | 6600*1200*1600mm |
Doublw winders, one for medical paper , one for film roller
Panasonic motor controlled
the Whole machine , we adopt BH-ZD Model system ,up down hot sealing .
with slitter, to cut into several bags .
rich experience in pouch bag making machine .
spare parts is easy find in your local
good and soonest after services
